4W/6W/8W/12W RGBW/RGBW LED Ceiling Light; DC12/24V Input; With 4/5 Wire PWM Driver Inside; 100 Degree Lighting Angle

Item No. 1005004484747486

4W/6W/8W/12W RGBW/RGBW LED Ceiling Light; DC12/24V Input; With 4/5 Wire PWM Driver Inside; 100 Degree Lighting Angle

€9.35

From €9.35 to €11.39 depending on options

Emitting Color: RGBW 5 wire
Size: DC24V
Wattage: 4W
Quantity
963 available

Delivery estimate

Usually delivered in about 7 days.

Checkout is coming soon.

Sold by
Expydrop
Ships from
The supplier's warehouse

Expydrop buys this item from the supplier and has it shipped directly to you. How it works

Specifications

Brand Name
pingpinghanhansun
Is Smart Device
no
Lighting Housing
N
Power Source
DC
Origin
Mainland China
Is Bulbs Included
No
Is Include PCBA
Y
High-concerned chemical
none
Power Tolerance
2%
Model Number
ESP-PWM-downlight
Finish
Brushed Nickel
Is Batteries Included
No
Light Source
LED bulbs
Use
Industrial
Certification
CE, CCC, ROHS, ce, FCC
Voltage
12 V
Application
Foyer
Item Type
Spotlight
Warranty
50000
Is Dimmable
Yes
Body Material
aluminum

Description

Parameter Performance:


Material:                         Die-cast aluminum

Input voltage:                 DC12V or DC24V

Power Efficiency:            90

Beam Angle:                   100 degree

Led chip:                         USA Bridgelux

LED power:                     4W/6W/8W/12W

Led color:                      RGB or RGBW(warm white)

Lumen(Lm):                   4W: R: 100lm; G: 140lm; B: 501lm; W: 210

                                      6W: R: 190lm; G: 270lm; B: 95lm; W: 400

                                    8W: R: 300lm; G: 420lm; B: 150lm; W: 625

                                      12W: R: 300lm; G: 420lm; B: 150lm; W: 625



Size:                               4W:  68mm-50mm-43mm(outer diameter-open hole-height)

                                      6W: 90mm-75mm-43mm(outer diameter-open hole-height)

                                      8W: 110mm-90mm-43mm(outer diameter-open hole-height)

                                      12W: 120mm-100mm-43mm(outer diameter-open hole-height)


Control method:           4/5 wires PWM external control(VCC12V+,R-,G-,B-,W-)

                                      By normal RGB/RGBW controller or 4ch/5ch dmx constant voltage decorder,etc
