Item No. 1005006416618253
Chip LED RGB 250mA Light Source 3W 6W 9W 12W 15W 18W 24W 30W Spotlight For Luminously Disco DJ Lamp RGB LED Diode Accessories
From €2.27 to €5.03 depending on options
Delivery estimate
Checkout is coming soon.
- Sold by
- Expydrop
- Ships from
- The supplier's warehouse
Expydrop buys this item from the supplier and has it shipped directly to you. How it works
Specifications
- Brand Name
- DT&ZM
- High-concerned chemical
- none
- Origin
- Mainland China
- Certification
- CCC
- Item Type
- Ball
- 1411 2011 2820 Power
- 3W/6W/9W
- 1917 Power
- 12W/15W/18W/24W/30W
- 1411 2011 2820 Series parallel
- 3W-2B1C*3/6W-2B2C*3/9W-3B2C*3
- 1917 Series parallel
- 12W-2B4C*3/15W-2B5C*3/18W-2B6C*3/24W-2B8C*3/30W-2B10C*3
- Current
- 250mA
- Lumen
- 100lm/w
- Display value
- Ra≥70
- Chip crystal size
- 10*21mil
- 1411 Appearance dimensions
- 13.5*135mm(0.53*0.53inch)
- 2011 Appearance dimensions
- 20mm(0.79inch)
- 1917 Appearance dimensions
- 19*19mm(0.75*0.75inch)
- 2820 Appearance dimensions
- 28mm(1.10inch)
- 1411 Luminous surface size
- 11mm(0.43inch)
- 2011 Luminous surface size
- 11mm(0.43inch)
- 1917 Luminous surface size
- 17mm(0.67inch)
- 2820 Luminous surface size
- 20mm(0.79inch)
- Material
- Aluminum
- Thickness
- 1mm
- Thermal conductivity
- aluminum plate 2W/M.K
- Application location
- stage lights, holiday lighting, bars, outdoor landscape lighting
Description
Product details
Model: 1411
Power: 3W/6W/9W
Series parallel: 3W-2B1C*3/6W-2B2C*3/9W-3B2C*3
Current: 250mA
Lumen: 100lm/w
Display value: Ra≥70
Chip crystal size: 10*21mil
Appearance dimensions: 13.5*135mm(0.53*0.53inch)
Luminous surface size: Φ11mm(0.43inch)
Model: 2011
Power: 3W/6W/9W
Series parallel: 3W-2B1C*3/6W-2B2C*3/9W-3B2C*3
Current: 250mA
Lumen: 100lm/w
Display value: Ra≥70
Chip crystal size: 10*21mil
Appearance dimensions: Φ20mm(0.79inch)
Luminous surface size: Φ11mm(0.43inch)
Model: 2820
Power: 3W/6W/9W
Series parallel: 3W-2B1C*3/6W-2B2C*3/9W-3B2C*3
Current: 250mA
Lumen: 100lm/w
Display value: Ra≥70
Chip crystal size: 10*21mil
Appearance dimensions: Φ28mm(1.10inch)
Luminous surface size: Φ11mm(0.43inch)
Model: 1917
Power: 12W/15W/18W/24W/30W
Series parallel: 12W-2B4C*3/15W-2B5C*3/18W-2B6C*3/24W-2B8C*3/30W-2B10C*3
Current: 250mA
Lumen: 100lm/w
Display value: Ra≥70
Chip crystal size: 10*21mil
Appearance dimensions: 19*19mm(0.75*0.75inch)
Luminous surface size: Φ17mm(0.67inch)
Material: Aluminum
Thickness: 1mm
Thermal conductivity: aluminum plate 2W/M · K
Application location: stage lights, holiday lighting, bars, outdoor landscape lighting
Usage temperature: A radiator is required, and the temperature cannot exceed 65 degrees.
Welding conditions: The temperature of the electric soldering iron is 350 degrees Celsius, and the welding time is less than 2 seconds.
